| Ask Lasest Price | |
| Brand Name : | Rongta |
| Model Number : | RP203 |
| Certification : | CE CCC |
| Price : | $13 |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 100000 units per year |
| Delivery Time : | OEM/ODM 35-55 days |
2 inch Thermal Panel Parking Lot Ticket Machine RP203 58mm Panel Thermal Printer
Product Features:
1. Stylish and elegant appearance
2. Low noise and direct thermal printing
3. Automatic detecting paper, automatic memory printing
4. Support serial port(RS232C,TTL), and parallel port
5. Rich graphics/curve/text printing function
6. Easy to load paper
Product Parameters:
| Paper Working | Loading way | easy |
| Cutting way | divulsion(dentiform) | |
| Printer performance | Print method | Direct thermal print and auto paper feed |
| Printing density | 384 dots/line | |
| 8 dots/mm | ||
| Printing width | 48 mm | |
| Max Printer Speed | 85 mm/s(max.) | |
| dot distance | 0.125 mm | |
| Drawing/Bar code | word size(W*H mm) | 0.75*1 |
| ASCⅡ Character(W*H dots) | 16 lattice:8*16; 24 lattice:12*24 | |
| ASCⅡ Size(W*H mm) | 16 lattice:2*4; 24 lattice:1.5*3 | |
| drawing/bar code | suitable | |
| Testing Method | lacking paper testing | photoelectricity sensor |
| Control System | printer interface | TTL/RS232 |
| buffer | 32k | |
| Command System | ESC printer command/WH printing command | |
| Power | Woking Voltage | DC3.5V--9V (from7.2-5v,with highest speeed and excellent effect!) |
| Average electricity | less than 1.5A | |
| Max electricity | less than 3A | |
| Printer Mechanism | printing head lifespan | 50km |
| Paper | paper item | thermal paper |
| paper width | 58mm | |
| papaer thickness | 65±5um | |
| diameter of paper roll | 30mm | |
| Physics Specification | Environment adaptability | 0~55°C;-20~55°C |
| 10~90%RH | ||
| Storage temperature | –25~70°C | |
| 10~90%RH | ||
| Dimension (W*H*D mm) | 76.8mm*77.4mm*43.5mm |
|
|
